EPIC-M W/ Ti PL MOUNT / SIDE SSD

$43,000.00

SKU#: 710-0015

Qty:

Usually Ships Within 3-5 Business Days

EPIC-M is a high-performance, production-run DSMC® camera designed for professional still and motion image acquisition. Capture 5K images from 1-120 fps and take advantage of an arsenal of features such as HDRx, wireless remote control (via REDmote), and modular design – without the burden of dealing with a large, bulky system. DSMC modules, sensor upgrades and free firmware updates are just a few advantages of Obsolescence Obsolete. Made in the USA.

The EPIC-M Pack is a hand-assembled, non-production run camera. DSMC Side SSD Module and PL mount is included.

NOTE: Any collection or group of items placed as a single order that includes 1x EPIC brain and totals over $50,000 in invoiced value will receive the DRAGON sensor upgrade at no charge. Orders with multiple EPIC brains must meet or exceed the invoiced $50,000 per brain threshold in order to be eligible for the correlating DRAGON sensor upgrades.

SENSOR: 14 MEGAPIXEL MYSTERIUM-X™

PIXEL ARRAY: 5120 (h) x 2700 (v)

S/N RATIO: 66db

DYNAMIC RANGE: 13.5 stops, up to 18 stops with HDRx™

MAX IMAGE AREA: 5120 (h) x 2700 (v)

LENS COVERAGE: 27.7mm (h) x 14.6mm (v) x 31.4 mm (d)

DEPTH OF FIELD: Equivalent to S35mm (Motion) / APS-H (Still) lenses
Equivalent to 16mm (Motion) lens in 2K RAW

ACQUISITION FORMATS: 5K RAW (Full Frame, 2:1, 2.4:1 and Anamorphic 2:1)
4.5K RAW (2.4:1)
4K RAW (16:9, HD, 2:1 and Anamorphic 2:1)
3K RAW (16:9, 2:1 and Anamorphic 2:1)
2K RAW (16:9, 2:1 and Anamorphic 2:1)
1080p RGB (16:9)
720p RGB (16:9)

PROJECT FRAME RATES: 23.98, 24, 25, 29.97, 47.96, 48, 50, 59.94 fps, all resolutions

DELIVERY FORMATS* 4K : DPX, TIFF, OpenEXR (RED RAY via optional encoder)
2K : DPX, TIFF, OpenEXR (RED RAY via optional encoder)
1080p RGB or 4:2:2, 720p 4:2:2 : Quicktime, JPEG
Avid AAF, MXF. 1080p 4.2.0, 720p 4:2:0 : H.264, .MP4

PROGRAM OUTPUT: HD-SDI Clean Feed
2K RGB, 1080p RGB or 4:2:2, 720p 4:2:2
SMPTE Timecode, HANC Metadata, 24-bit 48Khz Audio

MONITOR OUTPUT: HD-SDI and HDMI with Frame Guides and Look Around
2K RGB, 1080p RGB or 4:2:2, 720p RGB or 4:2:2
SMPTE Timecode, HANC Metadata, 24-bit 48Khz Audio

DIGITAL MEDIA REDMAG (SSD) Module: (64, 128, 256GB Media)

REDCODE™ 12 and 16-bit RAW : Compression choices of 18:1 to 3:1
1-120 fps 5K, 4.5K
1-150 fps 4K
1-200 fps 3K
1-300 fps 2K

AUDIO: 2 channel, uncompressed, 24 bit, 48KHz.
Optional 4 channel, and AES / EBU digital audio.

MONITORING OPTIONS: RED LCD 5" Touchscreen Display
BOMB EVF™ High Definition Viewfinder

REMOTE CONTROL: Wireless, Ethernet, RS232, GPI Trigger

WEIGHT: 5lbs. Body only

CONSTRUCTION: Aluminum Alloy

TEMPERATURE RANGES: Operating Range: 0˚C to +40˚C (32˚F to 104˚F)
Storage Range: -20˚C to +50˚C (-4˚F to 122˚F)
